TK Self-clinching Standoffs

TK Self-clinching Standoffs

  • Precisely space mating panels and chassis with a permanent self-clinching standoff design.
  • Install in sheets as thin as .040" (1.00mm), with the standoff head seated flush using parallel punch-and-anvil surfaces.
  • Feature thru-hole threads to provide flexibility with mating fastener lengths.
  • Available in inch thread sizes 4-40, 6-32, 8-32, and 10-32, plus metric thread sizes M3 x 0.5, M3.5 x 0.6, M4 x 0.7, and M5 x 0.8.
  • Offered in inch lengths from .125" to 1.062" and metric lengths from 3mm to 25mm, depending on thread code and selected part number.
  • Available in aluminum, 300-series stainless steel, heat-treated carbon steel, and heat-treated 400-series stainless steel, with options for plain, passivated, or zinc clear chromate finishes.
