Dimensions
| Size Code | Nominal Washer Size | Type | Type Code |
T Thickness |
A Inside Diameter |
B Outside Diameter |
|||
|---|---|---|---|---|---|---|---|---|---|
| Basic | MAX / MIN | Basic | + / – | Basic | + / – | ||||
| #0 | 0 – .060 |
Narrow Regular Wide |
NAR REG WIDE |
.025 .025 .025 |
.028 / .022 .028 / .022 .028 / .022 |
.068 .068 .068 |
.000 / .005 .000 / .005 .000 / .005 |
.125 .188 .250 |
.000 / .005 .000 / .005 .000 / .005 |
| #1 | 1 – .073 |
Narrow Regular Wide |
NAR REG WIDE |
.025 .025 .032 |
.028 / .022 .028 / .022 .036 / .028 |
.084 .084 .084 |
.000 / .005 .000 / .005 .000 / .005 |
.156 .219 .281 |
.000 / .005 .000 / .005 .000 / .005 |
| #2 | 2 – .086 |
Narrow Regular Wide |
NAR REG WIDE |
.025 .032 .032 |
.028 / .022 .036 / .028 .036 / .028 |
.094 .094 .094 |
.000 / .005 .000 / .005 .000 / .005 |
.188 .250 .344 |
.000 / .005 .000 / .005 .000 / .005 |
| #3 | 3 – .099 |
Narrow Regular Wide |
NAR REG WIDE |
.025 .032 .040 |
.028 / .022 .036 / .028 .045 / .036 |
.109 .109 .109 |
.000 / .005 .000 / .005 .008 / .005 |
.219 .312 .406 |
.000 / .005 .000 / .005 .008 / .005 |
| #4 | 4 – .112 |
Narrow Regular Wide |
NAR REG WIDE |
.032 .040 .040 |
.036 / .028 .045 / .036 .045 / .036 |
.125 .125 .125 |
.000 / .005 .008 / .005 .008 / .005 |
.250 .375 .438 |
.000 / .005 .008 / .005 .008 / .005 |
| #5 | 5 – .125 |
Narrow Regular Wide |
NAR REG WIDE |
.032 .040 .040 |
.036 / .028 .045 / .036 .045 / .036 |
.141 .141 .141 |
.000 / .005 .008 / .005 .008 / .005 |
.281 .406 .500 |
.000 / .005 .008 / .005 .008 / .005 |
| #6 | 6 – .138 |
Narrow Regular Wide |
NAR REG WIDE |
.040 .040 .063 |
.036 / .028 .045 / .036 .045 / .036 |
.156 .156 .156 |
.000 / .005 .008 / .005 .008 / .005 |
.312 .438 .562 |
.000 / .005 .008 / .005 .008 / .005 |
| #8 | 8 – .164 |
Narrow Regular Wide |
NAR REG WIDE |
.040 .040 .063 |
.045 / .036 .045 / .036 .071 / .056 |
.188 .188 .188 |
.008 / .005 .008 / .005 .008 / .005 |
.375 .500 .625 |
.008 / .005 .008 / .005 .015 / .005 |
| #10 | 10 – .190 |
Narrow Regular Wide |
NAR REG WIDE |
.040 .063 .063 |
.045 / .036 .045 / .036 .071 / .056 |
.203 .203 .203 |
.008 / .005 .008 / .005 .008 / .005 |
.406 .562 .734 |
.008 / .005 .008 / .005 .015 / .007 |
| #12 | 12 – .216 |
Narrow Regular Wide |
NAR REG WIDE |
.063 .063 .063 |
.045 / .036 .071 / .056 .071 / .056 |
.234 .234 .234 |
.008 / .005 .008 / .005 .008 / .005 |
.438 .625 .875 |
.008 / .005 .015 / .005 .015 / .007 |
| 1/4 | 1/4 – .250 |
Narrow Regular Wide |
NAR REG WIDE |
.063 .063 .063 |
.071 / .056 .071 / .056 .071 / .056 |
.281 .281 .281 |
.015 / .005 .015 / .005 .015 / .005 |
.500 .734 1.000 |
.008 / .005 .015 / .007 .015 / .007 |
| 5/16 | 5/16 – .312 |
Narrow Regular Wide |
NAR REG WIDE |
.063 .063 .100 |
.071 / .056 .071 / .056 .071 / .056 |
.344 .344 .344 |
.015 / .005 .015 / .005 .015 / .005 |
.625 .875 1.125 |
.015 / .005 .015 / .007 .015 / .007 |
| 3/8 | 3/8 – .375 |
Narrow Regular Wide |
NAR REG WIDE |
.063 .063 .100 |
.071 / .056 .071 / .056 .112 / .090 |
.406 .406 .406 |
.015 / .005 .015 / .005 .015 / .005 |
.734 1.000 1.250 |
.015 / .007 .015 / .007 .030 / .007 |
| 7/16 | 7/16 – .438 |
Narrow Regular Wide |
NAR REG WIDE |
.063 .063 .063 |
.071 / .056 .071 / .056 .112 / .090 |
.469 .469 .469 |
.015 / .005 .015 / .005 .015 / .005 |
.875 1.125 1.469 |
.015 / .007 .015 / .007 .030 / .007 |
| 1/2 | 1/2 – .500 |
Narrow Regular Wide |
NAR REG WIDE |
.063 .100 .100 |
.071 / .056 .112 / .090 .112 / .090 |
.531 .531 .531 |
.015 / .005 .015 / .005 .015 / .005 |
1.000 1.250 1.750 |
.015 / .007 .030 / .007 .030 / .007 |
| 9/16 | 6/16 – .562 |
Narrow Regular Wide |
NAR REG WIDE |
.063 .100 .100 |
.071 / .056 .112 / .090 .112 / .090 |
.094 .094 .094 |
.015 / .005 .015 / .005 .015 / .005 |
1.125 1.469 2.000 |
.015 / .007 .030 / .007 .030 / .007 |
| 5/8 | 5/8 – .625 |
Narrow Regular Wide |
NAR REG WIDE |
.100 .100 .160 |
.112 / .090 .112 / .090 .174 / .146 |
.656 .656 .656 |
.030 / .007 .030 / .007 .030 / .007 |
1.250 1.750 2.250 |
.030 / .007 .030 / .007 .030 / .007 |
| 3/4 | 3/4 – .750 |
Narrow Regular Wide |
NAR REG WIDE |
.100 .100 .160 |
.112 / .090 .112 / .090 .174 / .146 |
.812 .812 .812 |
.030 / .007 .030 / .007 .030 / .007 |
1.375 2.000 2.500 |
.030 / .007 .030 / .007 .030 / .007 |
Material & Finish
| Material Code | Material Description | Finish Code | Finish Description |
|---|---|---|---|
| STL | Low Carbon Steel (STL) | Z | Zinc Clear |
| SS | Stainless Steel | P | Passivated |
| PLN | Plain |
Contact a PENCOM Account Representative for other material & finish options.
